In Progress Terminator 2 Restoration

Ant127

Site Supporter
Joined
Oct 17, 2020
Messages
185
Location
London
I finally got round to starting the restoration of my T2 this past weekend, and i thought I’d start a build log as it’s my first time attempting to restore a pin and thought it would be a good idea to share my build with you guys and to get some advice if and when I get stuck.

I’ve restored a few arcade machines in the past and with this being only my second pin, which I purchased at the tail end of last year, my initial intention was to do a full playfield strip down, fit some mods and basically use it as a way to learn more about the up keep of these machines and the hobby.

Overall the game was in ok playable condition when I got it. The cabinet had obviously had a hard life, and it had the usual broken plastics, damaged side rails and general heavy wear and tear. So the plan was to strip it down, install new art work, give the playfield a good clean, some powder coating and to replace the plastic/rubbers etc.

Upon closer inspection that plan has slightly evolved since then. There are a few areas on the playfield that has some heavy wear and damage to the clear coat and artwork underneath. So I thought I’d jump right in the deep end and decided I might as well do a full playfield swap as well.

Im estimating this will take me a few months and plan to keep adding updates here, on how it’s coming along and any problems , so any advice would be greatly appreciated.
